Thermomelt® Surface Temperature Indicating Sticks
Precision surface temperature indicating sticks for fast, low-cost measurements with superior accuracy
THERMOMELT® HEAT-STIK® markers are a quick, low-cost method to accurately measure surface temperatures of various metals and equipment. The stick-in holder design provides convenience and durability for long-lasting use in the workshop or in the field. Please note that the color of the Thermomelts are not a part of their function, since the temperature signal consists of melting. Indicator color is subject to change without notice.
Process:
The precise temperature is reached once the stick has fully melted
Process:
The precise temperature is reached once the stick has fully melted
Durability:
The Long-Lasting Stick represents a much higher value proposition
Durability:
The Long-Lasting Stick represents a much higher value proposition
Greater Size Than The
Leading Competitors
Leading Competitors
0
%
Accuracy:
Consistently accurate temperature readings with no calibration required
Accuracy:
Consistently accurate temperature readings with no calibration required
+/- 3% Celsius
+/- 1% Fahrenheit
Ideal For:
- Preheating
- Annealing
- Stress Relieving
- Post-Weld Heat Treating
- Interpass Temperature Monitoring
Made In
The USA
Preheating
Stress Relieving
Annealing
Interpass Temperature Monitoring
Post-Weld Heat Treating
Features:
- Shirt-Clip
- Adjustment Ring
- Protective Holder
Prevents breakage and improves handling
Thermomelt® Heat-Stik® Temperature Table
Part Number (SKU Code) |
Celsius (°C) |
Fahrenheit (°F) |
|---|---|---|
| 86436 | 52°C | 125°F |
| 86463 | 66°C | 150°F |
| 86481 | 79°C | 175°F |
| 86517 | 93°C | 200°F |
| 86544 | 107°C | 225°F |
| 86562 | 121°C | 250°F |
| 86589 | 135°C | 275°F |
| 86625 | 149°C | 300°F |
| 86661 | 163°C | 325°F |
| 86697 | 177°C | 350°F |
| 86715 | 191°C | 375°F |
| 86733 | 204°C | 400°F |
| 86751 | 218°C | 425°F |
| 86769 | 232°C | 450°F |
| 86787 | 246°C | 475°F |
| 86805 | 260°C | 500°F |
| 86823 | 288°C | 550°F |
| 86859 | 343°C | 650°F |
**All These Marker Colours Are Low In Chlorides, Halogens And Sulfurs For Low Corrosion Marking Requirements**
Conforms To:
NIST Traceable
AWS D1.1
ANSI/ASME Code B32.1 & B31.3
ASME Code Sec. I, III, and VII
