NEW
Hand-Held
Tungsten
Electrode
Grinder
Tungsten Grinder
- News, Product Releases
- Published:
Parweld brings you the convenient Hand-Held Tungsten Electrode Grinder, a portable and efficient tool designed for sharpening tungsten electrodes used in TIG welding. This compact grinder allows welders to easily maintain and sharpen their tungsten electrodes on-site, ensuring optimal performance and arc quality.
NEW FOR
Specifications
Kit Contents
Tungsten Grinder Hand-Held Device
Carry Case
UK Plug or EURO Plug Available
UK Plug or EURO Plug Available
Dust Cover
HEX Key For Grinding Disc
- Tungsten Grinder Tool
- Dust Cover
- HEX Key For Grinding Disc Release
- Practical Carry Case
- UK Plug/Europlug Option
Technical Features
Diamond Faced Disc
High-Quality Double-Sided Diamond Faced Grinding Disc, with Variable Speed, provides precision grinds on various angles, ensures extended life and prevent tungsten contamination common with workshop grinding wheels.
Grinding Angles
The grinder features an adjustable angle guide, allowing you to select the desired grind angle (Angles – 15°, 18°, 22.5° and 30°) for different welding applications.
15°
18°
22.5°
30°
Electrode Diameters
The grinder is capable of grinding Tungsten Electrodes from sizes 1.0mm to 4.0mm in diameter.
1.0mm - 4.0mm
Other Features
Length Cutting
The Length Cutting Function allows for accurate trimming of Tungsten Electrodes to the desired length. Simply align the electrode with the scale on the device. With the device powered on, the grinding wheel will cut to the marked length.
End Dressing Option
The End Dressing Function allows for meticulous shaping of the Tungsten Electrode's tip. By carefully removing excess material, this feature helps to optimize arc stability, reduce electrode wear, and improve overall welding quality.
Power Supply
The grinder is available with two input voltage options: the 16A 110V Plug (PWTG01-110) or the 220V Europe / 230V UK (PWTG01-230) option. The appropriate power supply plug is fitted to the device in either Europlug for European Users or UK plug for UK Users.
110V
Input
230V (UK Spec) / 220V (EU Spec)
Input
User Benefits
Portable with Carry Case FOr On-Site Use
long-lasting performance
prevents tungsten contamination
easily maintain and sharpen Electrodes
Visual Demonstration
Jonathan
Group Technical Director
Tungsten Electrodes From Parweld
PURE
99.9% Tungsten
Suitable for AC Welding on Carbon Steel, Stainless Steel, Nickel and Titanium.
ZIRCONIATED
99.2% Tungsten and 0.8% Zirconium
Suitable for AC Welding on Carbon Steel, Stainless Steel, Nickel and Titanium.
CERIATED (2%)
98% Tungsten and 2% Cerium
Suitable for DC welding at low current. Can be used fully in AC processes.
THORIATED (2%)
98% Tungsten and 2% Thorium
Suitable for DC Welding on Carbon Steel, Stainless Steel, Nickel and Titanium.
LANTHANATED (1%)
99% Tungsten and 1% Lanthanum
Suitable for DC Welding on Carbon Steel, Stainless Steel, Nickel and Titanium.
LANTHANATED (2%)
98% Tungsten and 2% Lanthanum
Suitable for DC Welding on Carbon Steel, Stainless Steel, Nickel and Titanium.
GOLD
98.5% Tungsten and 1.5% Lanthanum
Suitable for DC Welding on Carbon Steel, Stainless Steel, Nickel and Titanium.
3 ELEMENT
98.34% Tungsten, 1.5% Lanthanum, 0.08% Zirconium and 0.08% Yttrium.
Suitable for both AC and DC Welding.
Find Tungsten Electrodes Available From Your Nearest Parweld!
