XTM 201i

200A MIG Inverter Machine

XTM 201i

200A MIG Inverter Machine

Product Code (SKU):   Parweld-MIG-201 Categories: , , Product Tags: , , , , , , ,

£0.00

For More Info Please Call Sales:

UK & Éire Sales:

Rest of the World ( Export ) Sales:

Please Call Sales To Place An Order:

Portable 230V Single Phase MIG Power Source Inverter Welding Machine from Parweld. The XTM 201i is able to cope with inputs which fluctuate by +/-15% & can be used with the majority of generators. The smooth DC output ensures excellent arc characteristics. Materials up to 4mm can be welded with ease. Synergic control provides rapid setting. Lightweight construction means the machine is very portable and the removable Euro connection torch makes for easy transport and storage. Can be used in MMA, Lift TIG, MIG manual and synergic with or without GAS. Wire sizes of 0.8-1.0mm can be used with ease. The machine is housed in a steel case with an integrated carry handle.

Key Features Include:

  • 230V Single Phase Machine
  • Synergic MIG
  • Lift TIG and MMA Welding
  • Compact and Portable
  • 200A @ 25% Duty Cycle
  • Gas or Gasless Operation Options
  • 2T / 4T Trigger Latching
  • Accepts 5kg (200mm) Spools
  • Supplied with 3m Earth Lead
Weight 15.5 kg
Dimensions 469 × 223 × 421 mm
Phase

Single Phase

Machine Style

Compact, Portable

Machine Type

Inverter

Maximum Current

200A DC

Duty Cycle

200A @ 25% Duty Cycle

Input Voltage

230V 1P

Voltage

18-26.5V

Feed Box

2 Roll Drive

Input Current (Eff)

18A

Output

DC

Wire Feed Speed

2-15m/min

Wire Size

0.6-0.8mm

Spool Size

100mm (1kg), 200mm (5kg)

Minimum Fuse Rating

16A

KVA

10.2

Generator Size (Requires AVC)

13 KVA

Cooling

Air, Fan, Forced

Comes With

3m Earth Cable, 3m Input Cable, Gas Hose

Ideal for Applications

Agricultural, DIY, Light Industrial Manufacturing, Maintenance Repair, Sheet Metal Work, Site Welding, Training

Special Features

2T/4T Trigger Latching, Lift TIG and MMA, Synergic MIG

Warranty

5 Year Warranty

Conforms To

IP23S, ISO/IEC 60974-1, ISO/IEC 60974-6 & RoHS compliant
