XTS 166
160A MMA Inverter + Remote Control
XTS 166
160A MMA Inverter + Remote Control
£0.00
For More Info Please Call Sales:
UK & Éire Sales:
Rest of the World ( Export ) Sales:
Please Call Sales To Place An Order:
The XTS 166RC is a professional level MMA inverter suitable for site and workshop use. This machine will run rutile and cellulosic electrodes up to 3.2mm. The XTS 166 can accept an optional remote current control for remote working. TIG welding with steel and stainless steel can be performed.
The XTS 166RC is able to cope with inputs which fluctuate by +/-15% & can be used with the majority of generators. The machine is housed in a rugged steel case. A carry case is available as an optional extra.
Key Features Include:
- Remote Control Option for Rutile and Low Hydrogen Electrodes
- Dual Voltage 110V / 230V Single Phase PFC
- 160A @ 40% Duty Cycle
- Digital Display for Easy Setting
- Suitable for Lift TIG Mode
- Generator Friendly
- Lightweight at just 7kg
- 81V OCV
- Easy electrode re-striking with hot start (MMA)
- Connections 35-50mm twist lock
| Weight | N/A |
|---|---|
| Dimensions | N/A |
| Phase | Single Phase |
| Machine Style | Compact |
| Machine Type | Inverter |
| Maximum Current | 10-125A (110V), 10-160A DC (230V) |
| Duty Cycle | 160A @ 40% Duty Cycle |
| Input Voltage | 110V 1P, 230V 1P |
| No Load Voltage | 81V |
| Max Electrode Size | 3.2mm |
| Input Current (Eff) | 14A |
| Output | DC |
| Cable Connection | 35-50 Dix |
| Minimum Fuse Rating | 16A, 32A |
| KVA | 5.6 |
| Generator Size (Requires AVC) | 7 KVA |
| Cooling | Air, Fan, Forced |
| Enclosure Protection | IP23S |
| Comes With | 3m Cable, 3m Earth Lead, Electrode Holder, Remote Control |
| Ideal for Applications | Agricultural, DIY, Metal Fabrication, Remote Working, Site Welding |
| Special Features | Generator Friendly, Lift TIG Mode, Re-Striking, Re-Striking with Hot Start, Remote Current Control |
| Warranty | 3 Year Service, 3 Year Warranty |
| Conforms To | IP23S, ISO/IEC 60974-1, ISO/IEC 60974-6, RoHS Compliant |
