XP A30 (ER70S-A1) Wire
Creep Resistant TIG Wire
XP A30 (ER70S-A1) Wire
Creep Resistant TIG Wire
£0.00
For More Info Please Call Sales:
UK & Éire Sales:
Rest of the World ( Export ) Sales:
Please Call Sales To Place An Order:
TIG/GTAW Wire for 0.5% Mo steels. These steels are commonly used at service temperatures up to 500°C and for some subzero structural applications.
The 0.5% alloying improves creep performance compared to CMn steels and sees the alloy being used for boiler, pressure vessel and piping construction.
The good general mechanical properties also ensures use in general structural engineering applications.
Welding Positions:
!["Welding]("https://great-villani.77-68-22-151.plesk.page/staging/wp-content/uploads/2022/07/Welding-Positions-2-300x51.png")
| Weight | 5 kg |
|---|---|
| Dimensions | N/A |
| Material | Low Alloy |
| Temperature | 20?C |
| Shielding Gas | Pure Argon |
| Current Type | DC- |
| Elongation 4d/5d | ?19/20% |
| Tensile Strength Rm | ?530MPa |
| 0.2% Proof Stress Rp 0.2 | ?460MPa |
| Chemical Composition (%) | C = 0.10, Mn = 1.15, Mo = 0.50, Si = 0.60 |
| Grade | ER70S-A1 |
| Set Size | Single Box |
| Conforms To | AWS A5.28 ER70S-A1, EN ISO 21952-A: W MoSi, EN ISO 636-A: W 46 4 2Mo |
