Parweld - Welding The Future

XTM 211Di

200A 4 in 1 Multi-Process Inverter Machine

XTM 211Di

200A 4 in 1 Multi-Process Inverter Machine

£0.00

For More Info Please Call Sales:

UK & Éire Sales:

Rest of the World ( Export ) Sales:

Please Call Sales To Place An Order:

The XTM 211Di MIG Inverter has 4 different processes available to the user making it ideal for the welding of Steels, Stainless Steels and Aluminium using the MIG, AC TIG, DC TIG or MMA processes. The machine uses auto polarity switching so there is no need to change the work lead connections on the front of the machine. Instant swapping between the MIG and TIG processes with one touch of the torch trigger makes it well suited to pipe applications or multi process workshops. The multi-language digital user interface rapidly gets you to the correct machine setting with minimal process knowledge, on site or in the workshop.

Key Features Include:

  • Easy to follow Digital Interface
  • Large high quality colour screen with multi-language function.
  • Adjust machine parameters from the MIG torch handle
  • View and adjust machine parameters from the MIG torch handle that is equipped with OLED Digital Display
  • HF Start TIG
  • Instant swapping between MIG and TIG process with one touch of the torch trigger
  • Rapid synergic setup for MIG, TIG & MMA Welding
  • MIG Weld, down to 0.9mm thick material
  • Memory function for all processes to save and recall welding programs
  • Pulse TIG function for superior arc control
  • Supplied with MMA lead set, input cable and 2 gas hoses
  • 15Kg (300mm) Spool Size
  • Welding Capacity (230V input)

**PLEASE NOTE – The TR007 Trolley is only compatible with Serial Numbers 2007 or Higher**

Weight 27.8 kg
Dimensions 615 × 275 × 495 mm
Phase

Single Phase

Machine Style

Compact, Portable

Machine Type

Inverter

Maximum Current

140A DC, 200A DC

Duty Cycle

200A @ 25% Duty Cycle

Input Voltage

110V 1P, 230V 1P, Dual Voltage, Smart Switching

Voltage

110-200V (MMA), 140-200V (MIG), 140-200V (TIG)

Feed Box

2 Roll Drive

Input Current (Eff)

MIG – 21.4A @ 110V / 15A @ 230V, TIG – 20.5 @110V / 11.3A @ 230V, MMA – 20.6 @110V / 15.4A @ 230V

Output

DC

Wire Size

0.6-1.0mm

Spool Size

200mm (5kg), 300mm (15kg)

Minimum Fuse Rating

16A, 32A

KVA

7.8

Generator Size (Requires AVC)

10 KVA

Enclosure Protection

IP23S

Cooling

Air, Fan, Forced

Comes With

3m Earth Cable, 3m Input Cable, CKE MMA Lead, Digital User Interface, Downloadable Mobile Application Option for Remote Mobile/Tablet Device Operation, Gas Hose, Multi-Language Functions

Special Features

Digital User Interface, Pulse TIG function for superior arc control, Smart Switching Dual Voltage, Synergic Control, Synergic Welding Rapid Set Up

Warranty

3 Year Service, 3 Year Warranty

Conforms To

IP23S, ISO/IEC 60974-1, ISO/IEC 60974-6 & RoHS compliant

3 reviews for XTM 211Di

  1. Bret Bates

    My boss got me this, I got the app on my phone as well, awesome bit of kit, the presets are not spot on but you can fine tune.

  2. Small Garage Workshop

    Great Machine those, as I have 2 and totally unbeatable for the money

  3. Christopher Gould

    Not enough is made of the fact that this is an AC/DC TIG machine as well as being a great MIG machine, really simple to use and the price is spot on!

Only logged in customers who have purchased this product may leave a review.

XTM211Di Manual

Download

Operator Manual for 4-in-1 Multi-Process MIG Digital Inverter Welding Power Source Machine - XTM 211 Di - Issue Date 2022
